一、 適用范圍
適用于工民鉆井、地溫鉆井，具有鉆孔直徑大、鉆孔深、進尺快，靈活高效等優點。
二、 技術參數
|
型號model |
|
|
|
整機重量Gross weight |
T |
3.8 |
|
外型尺寸Dimension |
mm |
3800*1550*2350 |
|
鉆孔直徑Aperture |
mm |
130-254 |
|
鉆孔深度Drilling depth |
m |
180 |
|
一次性推進長度Feed stroke |
mm |
3000 |
|
行走速度Travel speed |
km/h |
2.5 |
|
爬坡能力Grade ability |
Max. |
30° |
|
離地間隙Rising height from ground |
mm |
250 |
|
工作氣壓Wind pressure |
Mpa |
1.7-2.5 |
|
耗氣量Air consumption |
m3/min |
15-27 |
|
主機功率Engine power |
kw |
42-65 |
|
回轉速度Rotary speed |
rpm |
48-70 |
|
回轉扭矩Rotation torque |
N.m |
4200-5600 |
